Click "clear points" to remove all points for the currently selected graph. Click "add point" to add a point to the burn graph. The tangential component is orthogonal to the radial and normal components. If this button is toggled to "trajectory lock" then the normal direction is in the direction of the instantaneous angular momentum. The normal component is normal to the initial orbital plane set through the latitude, longitude and the longitude of the ascending node if "trajectory lock" is shown. The radial component is always in the direction away from the center of the Earth. Select different components of the thrust vector by clicking on the corresponding tab. They only cover a common range of rocket diameter and weight.Selecting this icon causes the camera to follow the launched rocket as it moves along the trajectory. They require knowledge of total motor thrust, and assume medium Cd, air density, a neutral thrust curve, an average burn rate. Much simpler charts (only 5 pages!) based on motor total thrust ranges were prepared by Dean Roth and distributed by Tripoli Wisconsin as part of a larger packet of RSO information. They can be a little difficult to use, but very detailed, with 221 pages of tables.Ĥ. These are charts where you can look up altitude and time to apogee based on the selected Aerotech motor, rocket diameter, drag coefficient, air density, and rocket mass.

Andreas Mueller made Performance Nomograms for rockets with Aerotech motors. Online flight simulators, like or The Rocket Simulator.ģ. It is a full-featured rocket design (all internal and external components) and flight simulation program.Ģ.

SpaceCad is a commercial program that costs $80 and runs on Windows.

It is a full-featured rocket design (all internal and external components) and flight simulation program.

RockSim is a commercial program from Apogee Components that costs $125 and runs on Windows and Macs.

wRASP is derived from older programs going back to an original BASIC program written by Harry Stine in 1979.

#Free rocket simulation software free#

wRASP is another older and free Windows program that simulates the flight of a rocket in one dimension (one degree-of-freedom), allowing determination of how high a rocket might fly with a particular motor and what the best ejection delay time might be.

WinRoc is a free, older, but but simple and fast to use suite of Windows programs for flight simulation, and determination of optimal ejection delay.

Algorithms are tuned with wind-tunnel and actual flight data by the authors. RASAero is likely the most accurate simulation program, with the ability to accurately calculate aerodynamic coefficients as a function of speed.

#Free rocket simulation software software#

RASAero is a free, combined aerodynamic analysis and flight simulation software package for model rockets and high power rockets, amateur rockets, and sounding rockets.

#Free rocket simulation software android#

OpenRocket is written in Java, and will run on any platform with a Java runtime engine installed: Windows, Macs, Linux, Android smart phones & tablets, etc.

#Free rocket simulation software full#

Unlike most free programs, OpenRocket is a full design tool, allowing the user to fully configure a rocket, including all internal components, with the ability to make 3D views of the finished rocket, and print fin and ring templates.

#Free rocket simulation software simulator#

OpenRocket is a free, open-source, and fully featured model rocket simulator that allows you to design and simulate your rockets before actually building and flying them.

Expected altitudes can be determined in many ways:ġ. At the launch, the RSO or Prefect can help with this determination – there are Motor/Weight/Rocket diameter/Altitude charts at the RSO table. If you have questions, please consult the METRA Prefect or President.Įxpected altitudes should be determined by the flyer at home prior to coming to the launch as part of their planning. NOTE: The RSO will have final say whether the rocket can fly with the installed motors! If you select a motor that will give an unsafe flight profile (too little thrust for rocket weight), or is judged to be in danger of exceeding our waiver, you will NOT be allowed to fly.

For EX motors, flights must be under 90% of the waiver (4050′) per Tripoli rules. Under no circumstances can rockets fly higher than our FAA Waiver allows, 4500′ AGL. Flyers are REQUIRED to know the expected altitude their rockets will fly with the motor(s) installed.
